EP1 Schematic
EP1 Schematic
Please note that our EP1 has been superseded by our updated EP1plus.
Overview
CCM listened to your feedback and in 2016 we updated our EP1 to our EP1plus. This update allows the EP1plus to accommodate additional connections. Those connections can include the following:
- Door Monitoring
- LED Status Light Connection
- Accessory
You will not find these additional connections available on our older EP1's. If you find yourself installing one of our legacy EP1's, please use our EP1plus Schematic and ignore the 3-Pin Connecter.
When wiring an EP1 use the EP1plus schematic and ignore the J6 - 3Pin connector
You can find our default EP1PLUS schematic here
