A007 EPK (schematic)
Overview
Below you will find the schematic for A007 EPK as well as key operational features and additional support information to assist with your installation.
Installation Schematic: A007 EPK
- The emergency door Buzzer circuit can be utilized to transmit the deactivation signal from RVT button to the module. The red wire on the RVT should be connected in this configuration to stop feedback onto the door buzzers.
- If there is no Buzzer circuit please use a direct connection from the RVT blue wire to the EP1plus blue wire
- The brown activation wire is typically connected to the red overhead lights or another 12V source (eg. brakes).
Operation Features
- Activation occurs automatically after the ignition has been on for 10 minutes OR by use of the 8-way overhead red lights, whichever occurs first.
- Deactivates in Key OFF position
- 1 minute to perform the child check
- Horn will sound for 5 minutes if the child check is not completed.
- The door is monitored and needs to remain closed during deactivation
- The dome lights will illuminate for 1 minute after deactivation
- The dome lights will flash twice to confirm deactivation
Order Information
Module: A007 EPK
Upgraded Component Kit: AC31 (For dome light, accessory and pilot light feature, LED not supplied)
- A033: RVT - Deactivation Button
- P100: 6-Pin Wire Harness
- A026: 3-Pin Diode Wire Harness
- P038: 2-Pin Wire Harness
